Oriels Hydraulic Main Pin Thumb
The Oriel hydraulic main pin thumb was built with Swedish steel and is ready to be worked hard!
This application was manufactured to suit your bucket width and style, ensuring optimum efficiency and safety when handling large regular-shaped objects.
| Excavator Size Class (lbs) | Oriel Thumb Model |
Width (in) | Thumb Tip Radius (in): |
Retract Clearance (in) |
Thumb Weight (lbs) |
| Class 20: (4,500-6,000 lbs) | DMT02 | 6 | 25 | 11 | 130 |
| Class 30: (6,000-9,000 lbs) | DMT03 | 6 | 32 | 11 | 155 |
| Class 40: (9,000-14,000 lbs) | DMT06 | 16 | 39 | 19 | 330 |
| Class 80: (14,000-22,000 lbs) | DMT08 | 16 | 45 | 16 | 370 |
| Class 140: (22,000-33,000 lbs) | DMT14 | 27 | 54 | 21 | 800 |
| Class 150/160: (33,000-42,000 lbs) | DMT18 | 27 | 60 | 21 | 840 |
| Class 200: (42,000-55,000 lbs) | DMT20 | 31 | 69 | 23 | 1100 |
| Class 250: (55,000-65,000 lbs) | DMT25 | 31 | 72 | 23 | 1250 |
